Product Advantages
1.Employing high-performance industrial online electrodes that can operate stably for a long time
2.RS485 signal output, with strong anti-interference capability and longer transmission distance
3.Built-in temperature sensor for real-time temperature compensation
4.Integrated sealing design, with good sealing performance and resistance to static interference
5.Open communication protocol, enabling integration and networking with other devices
6.Simple operation, supporting online software upgrade
7.Electrodes can be replaced, resulting in lower long-term usage costs
Product Parameters
Testing method | LED touch screen display |
|---|
Display | "TFT touch screen, LED backlight, 800X480 resolution, 154X86mm display window |
|---|
Simulation output | 5 isolated 4-20mA current outputs, 2 normally open contact relays |
|---|
Operating environment | (5-50)℃, (0-90)%RH, protection class: IP65 |
|---|
Shell material | PC + ABS |
|---|
Operating voltage | 100~220 V AC ±10%, 50 Hz ±10% |
|---|
Scope of Application
It is widely applied in surface water, municipal sewage, industrial wastewater, sewage treatment, water treatment plants, industrial processes, aquaculture and other industries.
