Product Advantages
1.Employing high-performance industrial online electrodes that can operate stably for a long time
2.RS485 signal output, with strong anti-interference capability and longer transmission distance
3.Built-in temperature sensor for real-time temperature compensation
4.Integrated sealing design, with good sealing performance and resistance to static interference
5.Open communication protocol, enabling integration and networking with other devices
6.Simple operation, supporting online software upgrade
7.Electrodes can be replaced, resulting in lower long-term usage costs
Product Parameters
Detection method: Infrared scattering method
Range: (0 - 50 g/L) (Customizable)
Accuracy ≤ ±5%
Repeatability ≤ 3%
Resolution for suspended solids: 1 mg/L
Turbidity: 0.1 NTU
Response time: ≤ 10 seconds
Protection level: IP68, 60 meters underwater
Power supply / power consumption: (12 - 28) VDC / 0.6W (in non-cleaning mode)
Material: Stainless steel S316L + POM
Detection method | Infrared scattering method |
|---|
Range | (0 - 50 g/L) (Customizable) |
|---|
Turbidity | 0.1 NTU |
|---|
Accuracy | ≤ ±5% |
|---|
Repeatability | ≤ 3% |
|---|
Response time | ≤ 10 seconds |
|---|
Protection level | IP68, 60 meters underwater |
|---|
Power supply / power consumption | (12 - 28) VDC / 0.6W (in non-cleaning mode) |
|---|
Material | Stainless steel S316L + POM |
|---|
Scope of Application
It is widely applied in industries such as surface water, drinking water, municipal sewage, tap water, aquaculture, industrial wastewater, sewage treatment, cooling water circulation, process monitoring, etc.
